» Energy-saving and environmentally friendly
» Max. 6m arm, 1.5~6 Sec. adjustable
» Free-maintenance brushless DC motor
» 10 million MTBF & 100% duty cycle
» 7*24 hrs continuously work with long life
» Boom arm is bidirectional
» Manually control in case power off
Item NO. : PAB-SE2-SNSP
Order(MOQ): 1 Set
Product Origin : China
Color : Grey or customized
Lead Time : 3~5 working days
Warranty : 1 year
Certificates : CE
OEM : Available
| Opening/closing time | 1.5~3 sec. adjustable , or 3~6 sec. adjustable |
| Boom Arm | Max. 6m octagonal straight arm without rubber (Telescopic arm optional) |
| Motor | 120W Brushless DC24V motor |
| Motor rotation | 1850r/min |
| Duty Cycle | 100% |
| MTBF (Meantime Before Failure) | 10 million cycles |
| Controller | PWM variable frequency servo controller board |
| Commnication interface | RS 485 or TCP/IP(Optional) |
| Remote distance |
50~100mtr. |
| Housing material | 1.5mm cold-roller sheet |
| Housing Painting | Powder coating, 10 years without rust,shedding and fading |
| IP level | IP 54 |
| Housing size (H*W*D) | 1715mm×400mm×435mm |
| Package size | 1740mm×420mm×545mm |
| G.W | 55KG |
| Operating temperature | -40°c -75°c |
| Humidity | 10%-95% |
1) Solar panel:
Dimension: 350*670mm; Weight: 2KG
Peak Power: 40W(Max. power 45.5W)
Type: Grade A monocrystalline
Open-circuit voltage: 18-22V (±10%)
Short-circuit current: 18A(±10%)
Conversion Efficiency: 21% (±1.5%)
Design Lifespan: 15-25 years
2) Li-ion NCM Battery:
Capacity: 20Ah
Nominal Voltage: 24V
Charging Modes: standard charging, dedicated battery charging
Protection: includes dedicated protection circuit board
Standard Current: 25A
Cycle Life: around 2500 to 2600 cycles
3) Solar Controller:
Weight: 0.15KG
Smart display: supports Lead-acid, Gel and Lithium modes
Charging Current: 20A (±5%)
Operating Voltage: 9V-24V«
Terminal: 6
Parallel Connection Support: YES
Includes Heat Sink: YES
Safety: overcharge protection, over-discharge protection, trickle charding mode
